High-Speed Camera
SinceVision high-speed camera leverages advanced CMOS technology and proprietary architectures for elite motion analysis. Capturing microsecond-level changes with total precision, our systems achieve industry-leading speeds of 1.15 million FPS and resolutions up to 21MP. Engineered for aerospace, combustion, fluid mechanics, life sciences, and scientific research.
Product Advantages
Product Matrix
New product recommendations
Product Selection
| Model | Max. Resolution | Full Frame Rate | Max. Frame Rate | Min. Exposure Time | Cell Size(μm) | Data interface | Product Status | Compare | Favorites |
|---|---|---|---|---|---|---|---|---|---|
| SH8-120 | 1280×1024 | 20000FPS | 700000FPS | 150ns | 20μm | 10 Gigabit Ethernet compatible with 2.5Gbps 1Gbps | Published |
|
|
| SH8-125 | 1280×1024 | 25000FPS | 1000000FPS | 150ns | 20μm | 10 Gigabit Ethernet compatible with 2.5Gbps 1Gbps | Published |
|
|
| SH8-130 | 1280×1024 | 30000FPS | 1100000FPS | 150ns | 20μm | 10 Gigabit Ethernet compatible with 2.5Gbps 1Gbps | Published |
|
|
| SHS-202 | 1920×1080 | 2250FPS | 69200FPS | 100ns | 10μm | CoaxPress | Published |
|
|
| SHS-201 | 1920×1080 | 1100FPS | 34400FPS | 100ns | 10μm | CoaxPress | Published |
|
|
| SHS-103 | 1280×864 | 3600FPS | 88600FPS | 100ns | 10μm | CoaxPress | Published |
|
|
| SHS-101 | 1280×864 | 1800FPS | 44300FPS | 100ns | 10μm | CoaxPress | Published |
|
|
| SH6-505 | 2560×2016 | 4500FPS | 56000FPS | 1μs | 9μm | 10GigE/GigE | Published |
|
|
| SH6-504 | 2560×2016 | 3600FPS | 50000FPS | 1μs | 9μm | 10GigE/GigE | Published |
|
|
| SH6-503S | 2560×1920 | 3000FPS | 500000FPS | 100ns | 7.8μm | 10GigE/GigE | Published |
|
|
File
SinceVision-High-speed Camera-Product Brochure Hot New
PDF / 11.38MB
Product Manual
Download Now
Add to Download List
SinceVision-High-speed Camera-Product Brochure Hot New
PDF / 11.38MB
Product Manual
FAQs
-
1. What is the minimum exposure time for capturing hyper-fast events?
The cameras offer a minimum exposure time of 100ns. This capability is essential for freezing motion in applications such as explosion experiments, crack extension research, and laser melting pool observation.
-
2. Does the system support PIV (Particle Image Velocimetry) for fluid mechanics?
Yes, SinceVision cameras feature a specialized PIV double exposure mode. The SH6 and SH3-MINI series provide a 210ns cross-frame interval, which is critical for high-precision flow field testing and microfluidics.
-
3. Can the cameras operate in extreme environmental conditions?
Standard models are rated for -10°C to 50°C, but customized large-temperature versions are available that operate from -40°C to 65°C (or 70°C for the AIR series). The hardware is also built to withstand 200G impacts and meets industry standard certifications for stability.
-
4. How much internal storage is available for long-duration recording?
SinceVision provides some of the largest storage capacities in the industry. The systems support up to 320GB of high-speed RAM and an optional 24TB of customized non-volatile storage to accommodate massive data requirements.
-
5. Do these cameras support 4K or 5K high-resolution imaging?
Yes, the Ultra HD series is specifically designed for high-end research and broadcasting-grade quality. It features 5K resolution (5120x4096) at 1000 FPS and 4K resolution (4096x2048) at 2000 FPS.
