Observation of Jet Experiments with High-Speed Camera
Industry pain points and demands
Research into jet dynamics is fundamental in fluid mechanics, with applications spanning aerodynamics, combustion, and industrial spraying. High-speed cameras are essential for capturing real-time jet behavior, providing data on parameters like velocity distribution, pressure shifts, and vortex dynamics.
These insights help researchers refine jet flow models, improve equipment design, and enhance process efficiency. High-speed imaging ensures precise, detailed observation for analyzing the spatial and temporal characteristics of jet flows.
SinceVision Solution: SH3-103 High-Speed Camera
01Exceptional Imaging Capabilities: High-speed recording with superior resolution for detailed analysis of jet flow phenomena.
02Advanced Design: Features a compact build with excellent heat dissipation, leveraging 20-layer PCB stacking and 10Gbps Serdes technology for efficient performance.
03Flexible Storage: Supports up to 4TB of storage via its array parallel architecture, enabling extended high-speed imaging for complex experiments.
Camera Selection
| performance | |||||||
| resolution | Frame rate | Record time (memory) | Record time (hard disk) | ||||
| 16GB | 32GB | 64GB | 1TB | 2TB | 4TB | ||
| 1280 x 1024 | 3000FPS | 4.3 s | 8.6 s | 17.2 s | 3.7 min | 7.4 min | 14.8 min |
| 1280 x 800 | 3800FPS | 4.3 s | 8.6 s | 17.2 s | 3.7 min | 7.4 min | 14.8 min |
| 1280 x 512 | 6000FPS | 4.3 s | 8.6 s | 17.2 s | 3.7 min | 7.4 min | 14.8 min |
| 1280 x 256 | 12000FPS | 4.3 s | 8.6 s | 17.2 s | 3.7 min | 7.4 min | 14.8 min |
| 1280×128 | 24000FPS | 4.3s | 8.6s | 17.2s | 3.7min | 7.4min | 14.8min |
| 1280×8 | 200000FPS | 8.3s | 16.6s | 33.2s | 8.8min | 17.6min | 35.2min |
| specification | |||
| Model number | TYPE | SH3-103 | |
| Maximum resolution | Full Resolution | 1280 x 1024 | |
| Full shot speed | Full Frame Rate | 3000fps | |
| Maximum shooting speed | Maximum Frame Rate | 200000fp | |
| Minimum exposure time | Minimum Exposure Time | 1μs, customized for 100 NS | |
| Pixel size | Pixel Size | 14.6μm | |
| Standard memory | Standard RAM | 16G, 32G, and 64G are optional | |
| Extended memory | Extended Memor | 1T, 2T, and 4T are optional | |
| Dynamic range | Dynamic Range | 60dB | |
| Analog gain | Analog Gain | X 2, x 4, x 8 | |
| Bit depth | Bit Resolution | 8bit/10bit/12bit | |
| Shutter type | Shutte Mode | Global shutter | |
| Color | Color | Monochrome (M)/Colorful (C) | |
| ROI | ROI | Support | |
| Lens Mount | Lens Mount | E interface, can be connected to F interface, C interface, EF interface | |
| Data Interface | Data Interface | 10 Gigabit Ethernet, Adaptive Gigabit Ethernet | |
| Sensitivity | Sensitivity | ISO56000(M)；ISO21000(C) | |
| Fan Control | Fan Control | Supports on/off, adaptive speed based on temperature | |
| Operating Temperature/Humidity | Operating Temperature/Humidity | Standard -10~50 ℃, below 95% (without condensation), customizable -35~65 ℃ wide temperature version | |
| Video Signal Output | Video Signal Output | Ethernet | |
| Recording Mode | Recording Mode | Start, End, Center, Random, Manual | |
| Trigger Mode | Trigger Mode | Manual, IO, Image | |
| External Signal | External Signal | Input: trigger (TTL/switch) signal, synchronization signal, ready signal, event signal, IRIG Output: trigger, synchronization signal, ready signal | |
| Power Supply | Power Supply | DC24V | |
| Dimensions (excluding lens) | Dimensions (excluding lens) | 90D × 110W × 110H, excluding raised parts | |
| Weight | Weight | ＜1.6kg | |
| Power Consumption | Power Consumption | ＜30W | |
| Standard Accessories | Standard Accessories | Power cord × 1. AC adapter × 1. Network cable × 1. Camera control software × 1. User manual × 1. Factory certificate of conformity × one | |
